Máy chủ Dell PowerEdge R660xs

Giá liên hệ

Processor: 2 x Intel Xeon Scalable 4th
Memory: Hỗ trợ 16 Slot DDR5
Hard Drive:
- Tối đa 10 ổ đĩa SAS/SATA/NVMe 2.5″
- Tối đa 4 x 3.5″ ổ
Raid Controller: RAID Controller H755
Management: iDRAC9 Enterprise, 16G
Network Controller: 2 x 1 GbE LOM card
Power Supply: 2 x PSU hot swap
Form Factor: 1U rackmount

Danh mục: Máy chủ, Máy chủ – Thiết bị lưu trữ

Mô tả
Brand

Thông số kỹ thuật của server Dell R660xs (Specifications)

Processor	Up to two 4th Generation Intel Xeon Scalable processors with up to 32 cores per processor, air-cooled Support for up to 2 x 250W processors
Memory	Up to 16 x DDR5 RDIMMs (1TB max) NVDIMM: No DIMM Speed: Up to 4800 MT/s
Storage Controllers	• Internal Controllers (RAID): PERC H965i, PERC H755, PERC H755N, PERC H355, HBA355i • Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 NVMe SSD drives, or USB • External HBAs (non-RAID): HBA355e • Software RAID: S160
Drive Bays	Up to 4 x 3.5″ SAS/SATA/SATA Up to 8 x 2.5” SAS/SATA HDD/SSDs Up to 10 x 2.5” SAS/SATA HDD/SSDs or NVMe SSDs Rear: 2 x 2.5” SAS / SATA / NVMe w/ NVMe RAID (PERC 11 & 12) Internal: USB and Internal BOSS-N1 (2 x M.2 NVMe) for boot. No IDSDM
Power Supply	• 1800W Titanium 200—240 VAC or 240 HVDC, hot swap with full redundant • 1400W Platinum 100—240 VAC or 240 HVDC, hot swap with full redundant • 1100W Titanium 100—240 VAC or 240 HVDC, hot swap with full redundant • 1100W LVDC -48 — -60 VDC, hot swap with full redundancy • 800W Platinum 100—240 VAC or 240 HVDC, hot swap with full redundant • 700 W Titanium 200—240 VAC or 240 HVDC, hot swap with full redundant
I/O Ports	Front Ports • 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 2.0 • 1 x VGARear Ports • 1 x Dedicated iDRAC Ethernet port • 1 x USB 2.0 • 1 x USB 3.0 • 1 x Serial (optional) • 1 x VGA (optional for Direct Liquid Cooling configuration)Internal Ports • 1 x USB 3.0 (optional)
GPU	No GPU support
Form Factor	1U rack server

Brand

Dell
