Máy Chủ Dell PowerEdge R770

Giá liên hệ

Máy Chủ Dell PowerEdge R770

Processor: Intel Xeon 6 processors, with up to
144 cores
Memory: 32 DDR5 DIMM slots, Up to 6400 MT/s
Hard Drive:
- Tối đa 24 ổ đĩa SAS/SATA/NVMe 2.5″
- Tối đa 12 ổ đĩa 3.5″
Management: iDRAC10, 17G
Power Supply: 2 x PSU hot swap
Form Factor: 2U rackmount

Danh mục: Máy chủ, Máy chủ – Thiết bị lưu trữ

Dell

Mô tả
Brand

Thông số kỹ thuật server Dell R770 (Specifications)

Processor	Two Intel Xeon 6 Processors with up to 144 E-cores or 86 P-cores per processor
Memory	• 32 DDR5 DIMM slots, supports RDIMM 8 TB max, speeds up to 6400 MT/s • Supports registered ECC DDR5 DIMMs only
Storage Controllers	• Internal Boot: Boot Optimized Storage Subsystem (BOSS-N1 DC-MHS): HWRAID 1, 2 x M.2 NVMe SSDs or M.2 Interposer board (DC-MHS): 2 x M.2 NVMe SSDs or USB • Internal controllers: Front PERC H965i, Front PERC H975i*, Front PERC H365i
Drive Bays	• No backplane configuration • Up to 8 x EDSFF E3.S Gen5 NVMe (SSD) max 122.88 TB also comes with FIO configuration • Up to 16 x EDSFF E3.S Gen5 NVMe (SSD) max 245.76 TB also comes with FIO configuration • Up to 32 x EDSFF E3.S Gen5 NVMe (SSD) max 489.6 TB • Up to 8 x 2.5 inch SAS/SATA/NVMe (SSD) max 122.88 TB • Up to 8 x 2.5-inch Universal max 245.6 TB • Up to 16 x 2.5 inch SAS/SATA (SSD) max 61.44 TB • Up to 24 x 2.5 inch SAS/SATA (SSD) max 92.16 TB • Up to 16 x 2.5 inch SAS/SATA (SSD) + 8 x 2.5-inch NVME) max 92.16 TB • Up to 40 x EDSFF E3.S Gen5 NVMe (SSD) max 614.4 TB* • Up to 4 x EDSFF E3.S Gen5 NVMe (SSD) max 61.2 TB on the rear*
Power Supply	• 800 W Platinum 100—240 VAC or 240 VDC • 1100 W Platinium 100—240 VAC or 240 VDC • 1500 W Titanium 100—240 VAC or 240 VDC • 1100 W Titanium 100—240 VAC or 240 VDC* • 3200 W Titanium 200—240 VAC or 240 VDC • 800 W Titanium 100—240 VAC or 240 VDC* • 3200 W 277 VAC and 336 HVDC Titanium* • 1400 W -48VDC 60mm* • 1500 W 277 VAC and 336 HVDC Titanium* • 2400 W Titanium 100—240 VAC or 240 VDC* • 1800 W HLAC Titanium 200—240 VAC or 240 VDC*
I/O Ports	Front Ports: • 1 x USB 2.0 Type C port • 1 x USB 2.0 Type A port (optional) • 1 x Mini-DisplayPort (optional) • 1 x DB9 Serial (with front I/O configuration) • 1 x Dedicated ethernet port for iDRAC management Rear Ports: • 1 x Dedicated ethernet port for iDRAC management • 1 x VGA • 2 x USB 3.1 Type A ports Internal Ports: • 1 x USB 3.1 Type A port
Form Factor	2U rack server
