Máy chủ Dell PowerEdge XR11

Giá liên hệ

CPU Intel Xeon E-2334 (8M Cache, 3.40 GHz, 4C/8T)

RAM 16GB DDR4

DISK 1.2 TB HDD DELL SAS

Storage Controller PERC H755 adapter

Network 1Gbs

Power Supply 600W

Form Factor 1U

Tình trạng Đặt trước, hàng mới 100%

Danh mục: Máy chủ, Máy chủ – Thiết bị lưu trữ

Dell

Mô tả
Brand

THÔNG SỐ KỸ THUẬT:

Processor
Processor Type	One Intel Xeon E-2300 series processor with up to 8 cores or one Intel Pentium processor with up to 2 cores
Number of Processors	2
Form Factor
Form Factor	1U
Dimensions
W x H x D (mm,inch)	• Height – 42.8 mm (1.69 inches) • Width – 482 mm (18.98 inches) • Depth – 585.3 mm (23.04 inches) without bezel, 598.94 mm (23.58 inches) with bezel
Storage
Options	Front bays: • Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB • Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 128 TB
Memory
Memory	• Four DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s • Supports unregistered ECC DDR4 DIMMs only NOTE: For Pentium processor, maximum memory speed supported is 2666 MT/s
Expansion Slot
PCIe	• 1×8 Gen4 (x16 connector) low profile, half length • 1×8 Gen4 (x8 connector) low profile, half length • 1×4 Gen4 (x8 connector) for dedicated PERC only
Network Controller
Embedded NIC	2 x 1 GbE LOM
Network Options	NA
OpenManage Software
OpenManage Software	• OpenManage Enterprise • OpenManage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin
Storage Controller
Optional Controller	• Internal controllers (RAID): PERC H355, PERC H355f, PERC H345, PERC H345f, H755, H755f, HBA355i, HBA355f, S150 • Internal Boot: Internal Dual SD Module or USB or Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs • External HBAs (non-RAID): HBA355e
Power Supply
Power Supply	600W Platinum 100-240 VAC or 240 VDC redundant, hot swap
Fan
Fan	Up to four fans with full redundancy
GPU Options
GPU Options	Not supported
Cooling options
Cooling options	Air cooling
System Management
Embedded Management	• iDRAC9 • iDRAC Direct • iDRAC RESTful API with Redfish • iDRAC Service Module
Front I/O
Front I/O	• 1 x iDRAC Direct (Micro-AB USB) port • 1 x USB 2.0
Rear I/O
Rear I/O	• 1 x USB 2.0 • 1 x iDRAC ethernet port • 1 x USB 3.0 • 1 x Serial port • 1 x VGA
Security
Security	• Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TCM 2.0 optional
